Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine

Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine
Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine

Large Image :  Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine

Product Details:
Place of Origin: China-Jiangsu Province
Brand Name: Jiangsu Shenghuang
Certification: CE
Model Number: SH-800W
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: To Be Negotiated
Packaging Details: Carton Packaging
Delivery Time: 15-20 Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 800 Sets Per Month

Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine

Description
Product Name: Small Horizontal Wind Turbine Rated Power: 800W 1000W
Blade Quantity: 3 Customization: Voltage Frequency
Rated Voltage: 24V 48V Max Wind Speed: 45m/s
High Light:

Renewable Energy Small Horizontal Wind Turbine

,

1kW Horizontal Axis Wind Turbine

,

horizontal axis wind mills of modern design can

Renewable Energy Small Horizontal Wind Turbine 24V 48V 800W 1000W For Electricity



Jiangsu Shenghuang New Energy Technology Co..Ltd. is located in Wuxi Liangxi district Jinshan North science and Technology Industrial Park, is a factory commitment to wind generators, solar monitoring system, wind and solar complementary monitoring system, photovoltaic system, wind and solar complementary controller,inverter,Gel battery, Lithium Battery Development and integrated application of green energy saving and environmental protection technology enterprises.



The rotor of most horizontal axis turbines is located upwind from the support tower. Downwind fans have been made because they don't require additional mechanisms to stay in line with the wind. In high winds, the blades can also bend, reducing their swept area and thus their wind resistance. Despite these advantages, the upwind design is preferred because changes in wind loads can cause damage to the turbine as each blade passes behind the support tower.

Product Parameter

Model SH-A500 SH-A600 SH-A800 SH-A1000 SH-A2000
Rated Power 500W 600W 800W 1000W 2000W
Maximum Power 530W 630W 830W 1200W 2200W
Rated Voltage 24V/48V/96V 24V/48V/96V 48V/96V 48V/96V 48V/96V
Quantity of baldes 3/5 piece 3/5 piece 3/5 piece 3 piece 3 piece
Packing Carton Wooden Box Wooden Box Wooden Box Wooden Box
Start-up Wind Speed 3m/s
Rated Wind Speed 11m/s
Blade Material Nylon Fiber
Body Material Carbon Steel
Generator Type Three-phase AC Permanent magnet generator
Magnet Material NdFeB
Working temperature -40℃-80℃







































The advantages of horizontal axis wind turbines include the following.



  • It has high output power compared to vertical wind turbines.
  • Once the wind shear changes, the towers are exposed to stronger winds.
  • high efficiency.
  • Compared to vertical turbines, it is not expensive.
  • It has high reliability.
  • It has a high capacity ratio.
  • It's more consistent.
  • These turbines are self-starting.
  • In this turbine, the blades are located on the side of the turbine's center of gravity, which improves stability.
  • It bends the blades to give the turbine blades the best angle of attack.
  • Blades can also tilt the rotor during storms to reduce damage



Feature

1. Low Start-up Wind Speed
2. Flange Connection With Easy Installation
3. Certified with:CE, RoHS and ISO 9001 2000
4. High-efficiency generator

5. Blade Material:Nylon Fiber

6. Generator Type:Three phase AC Permanent Magnet Generator



Renewable Energy Small Horizontal Wind Turbine 24Volt 800W 1kW Horizontal Axis Wind Turbine 0







Application

1. Marine,&Boat

2. Streetlights

3. Home, Openning Plaza lighting.

4. Wind&Solar Hybrid System

5. Monitoring device

6. Factory





FAQ



Q1. Can I have a sample order for wind turbine generator?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?
A: 7-10 days for Sample preparing ,15-20 working days for mass production.



Q3. Do you have any MOQ limit for order?
A: Low MOQ, 1pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline,train and sea shipping also optional.



Q5. How to proceed an order for wind turbine generator?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Then in the end we arrange the production.



Q6: Are Small Wind Turbines Worth It?

Small wind turbines are a solid option, whether in the suburbs, living off the grid, or just for cost savings. They provide sustainable energy and significantly reduce your carbon footprint.
