Product Details:
|
| Product Name: | Lithium Ion Phosphate Battery | Rated Voltage: | 48V/96V/220V/380V/600V |
|---|---|---|---|
| Rated AH: | 100AH | Warranty: | 5 Year |
| Application: | Energy Storage/UPS | Cell Type: | Lithium Ion Phosphate |
| High Light: | UPS Renewable Energy Batteries,green energy battery storage 150AH,green energy battery storage 100AH |
||
The term "lithium ion" does not refer to a single electrochemical couple, but to a series of distinct chemical reactions, all characterized by the transfer of lithium ions between electrodes during charge and discharge reactions. Lithium-ion batteries do not contain metallic lithium; instead, ions are inserted into the structure of other materials, such as lithiated metal oxides or phosphates in the positive electrode (cathode), carbon (usually graphite) or titanium in the negative electrode (anode) Lithium oxide.
The term "lithium polymer" (or more precisely, lithium-ion polymer) refers to a lithium-ion design in which electrodes are held together by a porous polymer matrix. Injecting and immobilizing the liquid electrolyte into the porous matrix enables the electrode stacks to be assembled into foil-like "pouches" that offer geometric flexibility and improved energy density compared to cylindrical batteries. However, these advantages are less pronounced as batteries scale to larger capacities.
| Powerwall LiFePO4 Battery(48V 200Ah) | ||
| Technical Parameter | ||
| NO | Item | Parameters |
| 1.Performance | Type | LiFePO4 battery(CELL:3.2V100Ah) |
| Nominal Voltage | 51.2V | |
| Rated Capacity | 200Ah(0.2℃/25℃)(Min:198Ah) | |
| Operating Voltage Range | 42V-57.0V(Typical 51.2V) | |
| Charging Voltage | 57.0V | |
| Discharge Cut-off Voltage | 42V | |
| Charging Current(Max.) | 60A | |
| Discharge Current(Max.) | 100A | |
| Width | 435mm | |
| Height | 875mm | |
| Depth | 190mm | |
| Weight | 102Kg | |
| 2.Function | Installation Method | |
| Communication | RS485 | |
| Terminal Stud | M8 Bolt | |
| Alarm&Protection | Over Voltage,under Voltage,short circuit,over current,over temperature,low temperature protection etc. | |
| 3.Working Condition | Cooling Mode | Automatic Cold and hot |
| Altitude | ≤4000m | |
| Humidity | 15%-85% | |
| Operating Temperature |
Charge 0℃-45℃ Discharge -10℃-60℃ |
|
| Recommended Charge Temperature | 15℃-40℃ | |
| Recommended Discharge Temperature | 15℃-40℃ | |
| Recommended Storage Temperature | 0℃-35℃ | |
The battery storage system is charged by clean electricity generated by solar or wind turbine.
STEP 2: DISCHARGE
Product Feature
1. Lithium Ion Battery For Energy Storage
2. Rechargable
3. Over-charge,over-discharge and overload protections for batteries
4. Compatible with energy storage system
5. CE Certification
6. WIFI or Bluetooth communication is optional
Battery energy storage systems are rechargeable battery systems that store energy from solar arrays or wind turbine or the electric grid and provide that energy to a home or business. Because they contain advanced technology that regular batteries do not, they can easily perform certain tasks that used to be difficult or impossible.
The idea of combining solar panels and batteries is not new. Early solar pioneers often attached a series of oceanic deep cycle batteries to their solar arrays. Before net metering became commonplace, this was the only way to use stored solar energy at night. Modern battery energy storage systems are conceptually similar but more complex and powerful. If those old battery arrays were like flip phones, modern battery energy storage systems are like the latest smartphones—they have the same main functions, but everything else is worlds apart.
Modern battery energy storage systems often include built-in inverters and computer control systems. This means they are all-in-one turnkey systems that are simple to install, essentially maintenance-free, and require no effort or expertise from the owner. They are also weatherproof and safe for people and pets.
Q1 Is there an endless supply of lithium?
A1 The world's reserves of lithium is estimated at 38 million metric tons. So, there is probably enough lithium reserves to meet electric car batter needs for some time.
Q2. What is the advantage of Lithium Ion Phosphate Battery?
A2. Lithium iron phosphate batteries (LiFePO4 or LFP) have many advantages over lead-acid batteries and other lithium batteries. Longer life, maintenance free, extremely safe, light weight, improved discharge and charge efficiency, to name a few. LiFePO4 batteries aren't the cheapest on the market, but with their long life and zero maintenance, it's the best investment you can make in a while.
Q3. What system do you want, on-grid or off-grid?
A3. Both
Q4. Can I get the entire Wind and Solar system from there?
A4. Of course. Jiangsu Shenghuang New Energy Technology Co., Ltd. can provide energy solutions for the elderly. Have our own technical team to provide technical support. You just have to ask a technician to install it for you.
Q5. Can Lithium Batteries Power a House?
A8. A home needs several lithium-ion batteries to power it for a day or more. Lead-acid batteries have been around for decades, are less efficient, offer less storage space, are usually larger, and don't last as long. Lithium batteries can be partially charged without any adverse effects.
Q6. Are lithium-ion solar cells the best energy storage option?
A4:Lithium-ion solar cells are the best solar energy storage systems for everyday residential use because they take up little space but still store a lot of energy. Plus, their high mod means you can use more energy storage.
