Product Details:
|
| Product Name: | Small Horizontal Wind Turbine | Rated Power: | 600W 800W |
|---|---|---|---|
| Blade Material: | Nylon | Generator Type: | Three Phase Permanent Magnet Generator |
| Rated Voltage: | 24V 48V | Starting Wind Speed: | 3m/s |
| High Light: | IP65 Small Horizontal Wind Turbine,800W horizontal axis wind machine,600W horizontal axis wind machine |
||
Company Profile
Jiangsu Shenghuang New Energy Technology Co..Ltd. is located in Wuxi Liangxi district Jinshan North science and Technology Industrial Park, is a factory commitment to wind generators, solar monitoring system, wind and solar complementary monitoring system, photovoltaic system, wind and solar complementary controller,inverter,Gel battery, Lithium Battery Development and integrated application of green energy saving and environmental protection technology enterprises.
The construction of horizontal axis wind turbines can be done with different components. Thus, horizontal axis wind turbine components mainly include the foundation, nacelle, generator, tower and rotor blades.
A horizontal axis wind turbine includes a rotor shaft and a generator arranged on top of a tower. Small wind turbines use simple wind vanes, while large wind turbines use wind sensors connected through auxiliary motors. Most wind turbines contain a gearbox to rotate the blades from slow to fast, thus operating the generator.
Feature
1. Low Start-up Wind Speed
2. Flange Connection With Easy Installation
3. Certified with:CE, RoHS and ISO 9001 2000
4. High-efficiency generator
5. Blade Material:Nylon Fiber
6. Generator Type:Three phase AC Permanent Magnet Generator
Product Parameter
| Model | SH-A500 | SH-A600 | SH-A800 | SH-A1000 | SH-A2000 |
| Rated Power | 500W | 600W | 800W | 1000W | 2000W |
| Maximum Power | 530W | 630W | 830W | 1200W | 2200W |
| Rated Voltage | 24V/48V/96V | 24V/48V/96V | 48V/96V | 48V/96V | 48V/96V |
| Quantity of baldes | 3/5 piece | 3/5 piece | 3/5 piece | 3 piece | 3 piece |
| Packing | Carton | Wooden Box | Wooden Box | Wooden Box | Wooden Box |
| Start-up Wind Speed | 3m/s | ||||
| Rated Wind Speed | 11m/s | ||||
| Blade Material | Nylon Fiber | ||||
| Body Material | Carbon Steel | ||||
| Generator Type | Three-phase AC Permanent magnet generator | ||||
| Magnet Material | NdFeB | ||||
| Working temperature | -40℃-80℃ | ||||
Application
1.Marine,&Boat
2.Streetlights
3.Home, Openning Plaza lighting.
4.Wind&Solar Hybrid System
5.Monitoring device
6.Factory
FAQ
Q1. Can I have a sample order for wind turbine generator?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 7-10 days for Sample preparing ,15-20 working days for mass production.
Q3. Do you have any MOQ limit for order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline,train and sea shipping also optional.
Q5. How to proceed an order for wind turbine generator?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Then in the end we arrange the production.
Q6: Are Small Wind Turbines Worth It?
Small wind turbines are a solid option, whether in the suburbs, living off the grid, or just for cost savings. They provide sustainable energy and significantly reduce your carbon footprint.
Q7: Do you offer warranty for the products?
A: Yes, we offer 5 years warranty to our products.
Q8:What is the best generator for a wind turbine?
A:Permanent magnet synchronous generators.
