Product Details:
|
| Product Name: | Lithium Ion Phosphate Battery | Rated Voltage: | 12V/24V/48V/96V/220V |
|---|---|---|---|
| Rated AH: | 50AH/100AH/150AH/200AH | Warranty: | 5 Year |
| Application: | Energy Storage | Cell Type: | LiFePO4 Rechargeable Battery Cell |
| High Light: | Lithium Phosphate Battery 48V,200AH lfp lithium ion battery,100AH lfp lithium ion battery |
||
Lithium is the lightest metal and can float on water. It also has the largest electrochemical potential, making it one of the most reactive metals. These properties make lithium possible to achieve extremely high energy and power densities in high-power battery applications such as automotive and backup power.
Many variants of the basic lithium chemistry have been developed to optimize the battery for specific applications, or in some cases to bypass the original technology's patents. Lithium metal reacts violently with water and can ignite and burn. Early commercial batteries using metallic lithium cathodes were considered unsafe in some cases, however, modern batteries do not use free lithium, but instead combine lithium with other elements into more benign compounds that do not interact with water react.
A typical lithium-ion battery uses carbon as the anode and lithium cobalt oxide or lithium manganese compound as the cathode. Electrolytes are usually based on lithium salts in organic solvents.
| Powerwall LiFePO4 Battery(48V 200Ah) | ||
| Technical Parameter | ||
| NO | Item | Parameters |
| 1.Performance | Type | LiFePO4 battery(CELL:3.2V100Ah) |
| Nominal Voltage | 51.2V | |
| Rated Capacity | 200Ah(0.2℃/25℃)(Min:198Ah) | |
| Operating Voltage Range | 42V-57.0V(Typical 51.2V) | |
| Charging Voltage | 57.0V | |
| Discharge Cut-off Voltage | 42V | |
| Charging Current(Max.) | 60A | |
| Discharge Current(Max.) | 100A | |
| Width | 435mm | |
| Height | 875mm | |
| Depth | 190mm | |
| Weight | 102Kg | |
| 2.Function | Installation Method | |
| Communication | RS485 | |
| Terminal Stud | M8 Bolt | |
| Alarm&Protection | Over Voltage,under Voltage,short circuit,over current,over temperature,low temperature protection etc. | |
| 3.Working Condition | Cooling Mode | Automatic Cold and hot |
| Altitude | ≤4000m | |
| Humidity | 15%-85% | |
| Operating Temperature |
Charge 0℃-45℃ Discharge -10℃-60℃ |
|
| Recommended Charge Temperature | 15℃-40℃ | |
| Recommended Discharge Temperature | 15℃-40℃ | |
| Recommended Storage Temperature | 0℃-35 | |
The battery storage system is charged by clean electricity generated by solar or wind turbine.
STEP 2: DISCHARGE
Product Feature
1.Lithium Ion Battery For Energy Storage
2.Rechargable
3.Over-charge,over-discharge and overload protections for batteries
4.Compatible with energy storage system
5.CE Certification
6.WIFI or Bluetooth communication is optional
Battery energy storage systems are rechargeable battery systems that store energy from solar arrays or wind turbine or the electric grid and provide that energy to a home or business. Because they contain advanced technology that regular batteries do not, they can easily perform certain tasks that used to be difficult or impossible.
The idea of combining solar panels and batteries is not new. Early solar pioneers often attached a series of oceanic deep cycle batteries to their solar arrays. Before net metering became commonplace, this was the only way to use stored solar energy at night. Modern battery energy storage systems are conceptually similar but more complex and powerful. If those old battery arrays were like flip phones, modern battery energy storage systems are like the latest smartphones—they have the same main functions, but everything else is worlds apart.
Modern battery energy storage systems often include built-in inverters and computer control systems. This means they are all-in-one turnkey systems that are simple to install, essentially maintenance-free, and require no effort or expertise from the owner. They are also weatherproof and safe for people and pets.
FAQ
Q1. Can I have a sample order for wind turbine generator?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 7-10 days for Sample preparing ,15-20 working days for mass production.
Q3. Do you have any MOQ limit for order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline,train and sea shipping also optional.
Q5. How to proceed an order for wind turbine generator?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Then in the end we arrange the production.
Q6. Is it OK to print my logo on wind turbine product?
A: Yes. Please inform us formally before our production.
Q7: Do you offer warranty for the products?
A: Yes, we offer 5 years warranty to our products.
Q8:Customization available?
A:Yes,further requirement shall be confirmed before production.
