3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine

China Shenghuang New Energy Technology Co.,Ltd certification
China Shenghuang New Energy Technology Co.,Ltd certification
Customer Reviews
Fasten packing!Thanks for the good service!I will place mass order soon!

—— Zenia

I bough this style before,but it cannot produce electricity.I try buy same style from this supplier.I am so luck,and it is higher quality.The best is that it can produce electricity.

—— Lena

I'm Online Chat Now

3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine

3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine
3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine 3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine

Large Image :  3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine

Product Details:
Place of Origin: China-Jiangsu Province
Brand Name: Jiangsu Shenghuang
Certification: CE
Model Number: SH-A2000W
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: $530-$560/Piece
Packaging Details: Wooden Box
Delivery Time: 10-25 working days
Payment Terms: Negotiated, L/C, D/A, D/P, T/T, Western Union
Supply Ability: 800 sets per month

3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine

Name: 2kw Horizonal Wind Turbine Rated Power: 1-20kw
OEM/ODM: YES Rated Voltage: 12V/24V/48V/96V/220V
Connection Mode: Flange Connection System Configuration: On-grid/Off-Grid System
High Light:

3 Phase Permanent Magnet Wind Turbine


96V pm generator wind turbine


220V pm generator wind turbine

Three Phase Permanent Magnet Generator 2KW 3KW 48V 96V 220V Horizonal Axis Wind Turbine Generator With Glass Fibre Blade


Wind turbines work on a simple principle: instead of using electricity to make wind—like a fan—wind turbines use wind to make electricity. Wind turns the propeller-like blades of a turbine around a rotor, which spins a generator, which creates electricity.


The terms "wind energy" and "wind power" both describe the process by which the wind is used to generate mechanical power or electricity. This mechanical power can be used for specific tasks (such as grinding grain or pumping water) or a generator can convert this mechanical power into electricity.



Features of permanent magnet generator


1. High efficiency. Permanent magnet generator is an energy-saving product. The permanent magnet rotor structure eliminates the excitation power required to generate the rotor magnetic field and the mechanical loss of friction between carbon brushes and slip rings, which greatly improves the efficiency of the permanent magnet generator. The average efficiency of ordinary excitation generators is only 45% to 55% in the speed range of 1500 rpm to 6000 rpm, while permanent magnet generators can be as high as 75% to 80%.

2. The self-starting voltage stabilizer is adopted, and there is no need to increase the excitation power supply. The generator simply spins to generate electricity. When the battery is damaged, the car charging system can still work as long as the engine is running. If the car doesn't have a battery, just turn the handle or slide it and it will fire.

3. It is especially suitable for working in harsh environments with more humidity or dust.

4. Radio interference. The permanent magnet generator has no carbon brush and slip ring structure, which eliminates the radio interference caused by the friction between the carbon brush and the slip ring; eliminates sparks, and is especially suitable for working in an explosion-hazardous environment, reducing the generator's requirements for ambient temperature.


1.Low Start-up Wind Speed
2.Three Blades
3.Flange Connection with easy installation
4.Certified with CE,ROHS and ISO 9001 2000
5.Customized Colors
6.High-efficiency Three Phase PMG Generator






3.Home, Openning Plaza lighting.

4.Wind&Solar Hybrid System

5.Monitoring device




Product Parameter


Model SH-A1000 SH-A1500 SH-A2000 SH-A2500 SH-A3000 SH-A5000 SH-A10K SH-A15K SH-A20K
Rated Power 1KW 1.5KW 2KW 2.5KW 3KW 5KW 10KW 15KW 20KW
Maximum Power 1.2KW 1.7KW 2.2KW 2.7KW 3.2KW 5.5KW 11KW 17KW 22KW
Nominal Voltage 48V/96V 48V/96V 48V/96V 48V/96V 96V/120V/220V 120V/220V/380V 120V/220V/380V 120V/220V/380V 120V/220V/380V
Rotor Diameter 2.8m 3.2m 3.2m 3.6m 4.8m 5.6m 7m 8m 9.8m
Weight 60kg 70kg 70kg 80kg 160kg 150kg 260kg 320kg 380kg
Package Weight 70kg 80kg 88kg 95kg 176kg 310kg 400kg 390kg 440kg
Package Size(mm) 1660*380*420 1630*420*450 1630*420*450 1830*420*450 2550*480*500
Start-up Wind Speed 3m/s
Rated Wind Speed 11m/s
Survival Wind Speed 50m/s
Blade Quantity 3 piece
Blade Material FRP
Generator Housing Material Carbon Steel
Packing Wooden Box
Generator Type 3 Phase Permanent Magnet Generator
alnico magnet NdFeB
brake mode electromagnetism
The wind adjustment Automatically adjust to windward
Working temperature -40℃-80℃



3 Phase Permanent Magnet Wind Turbine 2KW 3KW 48V 96V 220V PM Generator Wind Turbine 0

Types of Wind Turbines

1.Horizontal-Axis Wind Turbine Generator

2.Vertical-Axis Wind Turbine Generator


Advantages of Applying Wind Turbine Generator


1. Clean, good environmental benefits;

2. Renewable and never exhausted;

3. The infrastructure construction period is short

4. The installed capacity is flexible.


How to Buy a Wind Turbine Generator That Suits You


To buy a small wind turbine that suits you, you must first look at the production of the wind turbine manufacturer. When we buy wind turbines, we must find a regular manufacturer. Generally speaking, most capable and large-scale manufacturers have a complete catalog of products, strong R&D capabilities, product quality in line with national standards. Especially checking for the motor parameters: the main technical parameters include start-up wind speed, rated wind speed, rated voltage, rated power, rated speed, etc.


Secondly, users should choose the corresponding small wind turbine according to their own use requirements and wind conditions. For example, on the mainland, due to the small wind, we should choose some small power generators, because it is easier to be driven and generate electricity by small winds.


In this way, if the user consumes a lot of electricity, they can buy several small wind turbines and use them in parallel, the effect is much better than buying high-power generators.At the same time, users should pay attention to the following points when purchasing wind turbines,check the packaging,see if the quantity and accessories are complete,turn each rotating part by hand to see if the rotation is continuous.



Company Profile


Jiangsu Shenghuang New Energy Technology Co..Ltd. is located in Wuxi Liangxi district Jinshan North science and Technology Industrial Park, is a factory commitment to wind generators, solar monitoring system, wind and solar complementary monitoring system, photovoltaic system, wind and solar complementary controller,inverter,Gel battery, Lithium Battery Development and integrated application of green energy saving and environmental protection technology enterprises.


Focus on the development of solar power, wind-solar power generation system integration,the business consists of wind and solar monitoring system, Wind Turbine Grid and off-grid system PV system equipment design and procurement, complete sets, feasibility study and installation commissioning .
