50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine

China Shenghuang New Energy Technology Co.,Ltd certification
China Shenghuang New Energy Technology Co.,Ltd certification
Customer Reviews
Fasten packing!Thanks for the good service!I will place mass order soon!

—— Zenia

I bough this style before,but it cannot produce electricity.I try buy same style from this supplier.I am so luck,and it is higher quality.The best is that it can produce electricity.

—— Lena

I'm Online Chat Now

50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine

50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine
50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine 50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine

Large Image :  50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine

Product Details:
Place of Origin: China-Jiangsu Province
Brand Name: Jiangsu Shenghuang
Certification: CE
Model Number: SH-A10KW
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: To Be Negotitaed
Packaging Details: Wooden Box
Delivery Time: 10-25 working days
Payment Terms: Negotiated, L/C, D/A, D/P, T/T, Western Union
Supply Ability: 800 sets per month

50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine

Name: 96V Horizonal Wind Turbine Customization: Colors/Voltage/Frequency
Frequency: 50Hz 60Hz Colors: Customized
Flange Connection/Customization: YES Generator: 3 Phase Permanent Magnet
High Light:

Horizontal Wind Turbine 10KW


96V horizontal axis turbine


60Hz horizontal axis turbine

Modern Design ODM OEM Horizontal Wind Turbine 10KW 96V With Flange Connection For Electricity


Wind turbines work on a simple principle: instead of using electricity to make wind—like a fan—wind turbines use wind to make electricity. Wind turns the propeller-like blades of a turbine around a rotor, which spins a generator, which creates electricity.


The terms "wind energy" and "wind power" both describe the process by which the wind is used to generate mechanical power or electricity. This mechanical power can be used for specific tasks (such as grinding grain or pumping water) or a generator can convert this mechanical power into electricity.


  • Stable power supply

With wind turbines, solar panels, and battery packs, you'll be one of the few people in the world to have electricity 24/7, 365 days a year. The sun produces energy during the day and the wind at night, and batteries store it for up to five days.


  • Reliable Energy Supply

With a hybrid energy system, you are hedging your bet. If the sun doesn't shine, you have wind to lean on. If the wind stops, you can turn to a backup generator or battery pack to keep you going. By taking this hybrid approach, you can get a more reliable energy system than the U.S. grid.


  • Device Friendly Energy Supply

Charge controllers in hybrid solar-wind systems provide a properly managed and consistent energy flow that is not always possible with conventional energy sources.


  • Minimal Lifecycle and Running Costs

Renewable energy systems are easy to maintain and inexpensive. Hybrid energy systems are even more cost-effective because the pressure is shared between different power generation systems.




1. Low Start-up Wind Speed
2. Three Blades
3. Flange Connection with easy installation
4. Certified with CE,ROHS and ISO 9001 2000
5. Customized Colors
6. High-efficiency Three Phase PMG Generator






3.Home, Openning Plaza lighting.

4.Wind&Solar Hybrid System

5.Monitoring device




Product Parameter


Model SH-A1000 SH-A1500 SH-A2000 SH-A2500 SH-A3000 SH-A5000 SH-A10K SH-A15K SH-A20K
Rated Power 1KW 1.5KW 2KW 2.5KW 3KW 5KW 10KW 15KW 20KW
Maximum Power 1.2KW 1.7KW 2.2KW 2.7KW 3.2KW 5.5KW 11KW 17KW 22KW
Nominal Voltage 48V/96V 48V/96V 48V/96V 48V/96V 96V/120V/220V 120V/220V/380V 120V/220V/380V 120V/220V/380V 120V/220V/380V
Rotor Diameter 2.8m 3.2m 3.2m 3.6m 4.8m 5.6m 7m 8m 9.8m
Weight 60kg 70kg 70kg 80kg 160kg 150kg 260kg 320kg 380kg
Package Weight 70kg 80kg 88kg 95kg 176kg 310kg 400kg 390kg 440kg
Package Size(mm) 1660*380*420 1630*420*450 1630*420*450 1830*420*450 2550*480*500
Start-up Wind Speed 3m/s
Rated Wind Speed 11m/s
Survival Wind Speed 50m/s
Blade Quantity 3 piece
Blade Material FRP
Generator Housing Material Carbon Steel
Packing Wooden Box
Generator Type 3 Phase Permanent Magnet Generator
alnico magnet NdFeB
brake mode electromagnetism
The wind adjustment Automatically adjust to windward
Working temperature -40℃-80℃



50Hz 60Hz Horizontal Wind Turbine 10KW 96V Horizontal Axis Turbine 0

What is the best material for wind turbine blades?

Most blades are made of glass fiber reinforced polyester or epoxy resin. Carbon fiber or Kevlar is also used as reinforcement. Nowadays, the possible use of wood compounds, such as wood epoxy or wood fiber epoxy, is being studied.



How many blades are best for a wind turbine?
Generally, most horizontal axis wind turbines have three blades. The decision to design a three blade turbine was a compromise. Due to its reduced resistance, the single blade design is the best number to achieve maximum efficiency,hwever,one-blade design makes the whole set of wind turbine generator not stable.



How can you increase the efficiency of a wind turbine?
Doubling the diameter of turbine blades will increase the available power of wind energy by four times. Therefore, if the wind speed is low, larger diameter turbine blades are needed to obtain the maximum wind power efficiency.



Why are 3 blade turbines preferred?
For three blades, the angular momentum remains constant, because when one blade is upward, the other two point to an angle. So the turbine can rotate with the wind.


What happens if a wind turbine spins too fast?

On the other hand, if the wind turbine rotates too fast, it may cause mechanical damage; And two create a "wall" to resist the wind to safely rotate the turbine to generate electricity. Most wind turbines have a maximum speed at which they can operate normally.



Will adding more blades to a windmill make it go faster?

Larger and longer turbine blades mean higher aerodynamic efficiency. Generating more electricity in a turbine means less energy is lost when it enters the transmission system and from there into the generator.



Why do some wind turbines not turn?
But why do you see that a stationary wind turbine may not turn? It is mainly for one of the following two reasons: they are being maintained or need to be maintained. The wind is not strong enough for them to operate, or the wind is too strong for them to operate
