3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System

3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System
3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System 3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System

Large Image :  3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System

Product Details:
Place of Origin: China-Jiangsu Province
Brand Name: Jiangsu Shenghuang
Certification: CE ISO
Model Number: Isolar SML 5.5K II
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: To Be Negotiated
Packaging Details: Carton Packaging
Delivery Time: 15-20 Working Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 800 Sets Per Month

3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System

Description
Product Name: 3.5KW Hybrid Solar Inverter Rated Power: 3.5KW
Rated Voltage: 24V/48V Communication: USB/RS232/GPRS/WIFI
Wave Form: PWM Output Current: 0-80A
High Light:

48 Volt Hybrid Solar Inverter

,

Hybrid Solar Inverter MPPT

,

3.5KW off grid hybrid solar inverter

Modern Design 3.5KW 24V 48V Solar Inverter MPPT Remote Monitoring With Off-grid System



Off-grid systems are built using AC or DC coupled power supplies. AC-coupled power supplies include common solar inverters, wind turbines, or backup generators (gensets), while DC-coupled power supplies include MPPT solar charge controllers or micro-hydro systems.



Whether the system is AC coupled or DC coupled usually depends on the size of the system. Most small systems less than 6kW are DC coupled and use efficient MPPT solar charge controllers. Large off-grid systems can be AC ​​or DC coupled, depending on the type of off-grid inverter charger used, and compatibility with different solar inverters (AC) or solar charge controllers (DC). Most modern multimode inverters can be AC ​​and DC coupled, which creates a very safe, flexible power system with multiple charging options and can be used when the main inverter shuts down, the backup generator fails, or the battery drains. Enable black start operation whenever possible.





Description of Product



1. What is a solar inverter and how does it work?

A solar inverter is a component in a solar panel system that converts the direct current (DC) captured by the solar panels into alternating current (AC). AC current is the standard current required to power your home appliances and connect them to the national grid. It is usually equal to 120 volts or 240 volts, depending on the country. If you don't have a solar inverter in your system, you won't be able to safely power your home with solar power.



2. What does a solar inverter do?

  • The ability to convert Direct Current to Alternative Current

  • Maximizing Power Output

  • Connecting With National Current

  • Feedbacking information about power production

  • Ensuring that your Solar Panel is operating safely



3.What is solar hybrid inverter?

Solar panels generate direct current, we know that inverters must convert the energy to alternating current to power your home appliances. However, solar cells store electricity in the form of direct current. Hybrid solar inverters are capable of converting direct current to alternating current, while also storing any excess direct current in solar cells or selling it to the grid. When you need stored energy, the electricity can be converted to AC power for your home to use.



4.What size of inverter do I need for solar?

Generally speaking,your size of wattage for inverter shall be at least equal to the wattage of your load capacity on user end,say if you have 10kw requirement on user end,then you need 10kw inverter.



5.Can solar inverter run without batteries.

Hybrid Solar Inverter can do,this type of system is attached to solar panels and to the power grid which supplies power from both.





Rated Power 3500W 5500W
Voltage 230VAC
Voltage Range 170-280VAC
90-280VAC
Frequency Range 50hz/60hz(Auto sensing)
AC Voltage Regulation 230V AC±5%
Surge Power 7000W 11000W
Efficiency(peak)PV to inverter 97%
Efficiency(peak)Battery to inverter 94%
Transfer Time 10ms/20ms
Battery Voltage 24VDC 48VDC
Floating Charge Voltage 27VDC 54VDC
Overcharge Protection 33VDC 63VDC
Maximum Charge Current 80A 80A
Maximum PV Array Power 5000W 6000W
MPPT Range@Operating Voltage 120-450VDC
Maximum PV Array Open Circuit Voltage 500VDC
Maximum Charging Current 100A 100A
Maximum Efficiency  98%
Dimension D*W*H(mm) 100*300*440
Net Weight(kgs) 11 12
Communication Interface USB/RS232/GPRS/WIFI(Optional)
Humidity 5%-95% Relative Humidity(Non-condensing)
Operating Temperature 0℃-55℃



3.5KW 24V 48 Volt Hybrid Solar Inverter MPPT Remote Monitoring With Off Grid System 0
